| Product Name: | Metal Working Alloy Milling Cutter | Material: | Carbide, Tungsten Cobalt Alloy, Carbide, Tungsten Cobalt Alloy, Cemented Carbide |
|---|---|---|---|
| Type: | End Mill | Coating: | AlTiN |
| Application: | Carbon Steel | HRC: | 45 |
| Advantages: | High Efficiency | Controlling Mode: | CNC Milling Machine |
| High Light: | HELICA coating tungsten steel Alloy Milling Cutter,HELICA coating CNC Alloy Milling Cutter ODM,tungsten milling cutters HELICA coating |
||
End Mill 4 Flute Hrc45 Coated Milling Cutters For Metal Working Tools
1.We not only supply all kinds of high quality solid carbide End Mills ,but also different types of Drill Bits,Reamers,Tool Holders,Cutter Heads,Saw Blades and Inserts.
2. We have 0.02mm-25mm different diameter and 38mm-150mm length Milling Cutters for your winner market.HRC45/55/60/65 ,1-6 flutes for you to choose.
3.OEM:Special Cutters Customized acceptable!Coated OEM also.We can produce according to your drawing,too.Or the hot deisgned recommend to you.
4. HS Code reference for you to control everything:8207709000.
5. Mixed size and types in one batch available.
6. For distributor,we can label your brands on cutters and plastic box.
Standard type
| Model No. | Flute Diameter (mm) | Flute length (mm) | Shank Diameter (mm) | Overall length (mm) |
| D1*3*D4*50 | 1 | 3 | 4 | 50 |
| D1.5*4.5*D4*50 | 1.5 | 4.5 | 4 | 50 |
| D2*6*D4*50 | 2 | 6 | 4 | 50 |
| D2.5*7*D4*50 | 2.5 | 7 | 4 | 50 |
| D3*8*D4*50 | 3 | 8 | 4 | 50 |
| D3.5*10*D4*50 | 3.5 | 10 | 4 | 50 |
| D4*10*D4*50 | 4 | 10 | 4 | 50 |
| D5*13*D6*50 | 5 | 13 | 6 | 50 |
| D6*15*D6*50 | 6 | 15 | 6 | 50 |
| D8*20*D8*60 | 8 | 20 | 8 | 60 |
| D10*25*D10*75 | 10 | 25 | 10 | 75 |
| D12*30*D12*75 | 12 | 30 | 12 | 75 |
| D14*45*D14*100 | 14 | 45 | 14 | 100 |
| D16*45*D16*100 | 16 | 45 | 16 | 100 |
| D18*45*D18*100 | 18 | 45 | 18 | 100 |
| D20*45*D20*100 | 20 | 45 | 20 | 100 |
