Product Details:
Payment & Shipping Terms:
|
| Product Name: | Gear Form Milling Cutter | Material: | Cemented Carbide |
|---|---|---|---|
| Flutes: | 4 | Plating: | Titanium Nitride Aluminide |
| Application: | CNC Milling Machining | Colour: | Silver |
| Shank Diameter: | 4mm | Package: | Custoimer Request |
| High Light: | non coating mill form cutter,cemented carbide mill form cutter,gear form milling SUNPU |
||
Cemented Carbide Forming Milling Cutter 4 Flutes
Product Description
Form milling cutters have not a standard definition, it's used for producing 2D and 3D contour surfaces. There are varying form cutters in different shapes, configurations, and for different applications. The form cutters can be made from alloy steel, solid carbide, brazed carbide, and HSS.
The form-cutting method uses a cutting tool that has the same form as the space between two adjacent teeth on a gear. This method is used for cutting gear teeth on a milling machine.
| Form Radius | Outside Dia. | Width | Hole Dia. |
| 1 | 50 | 6 | 16 |
| 1.25 | |||
| 1.6 | 8 | ||
| 2 | 10 | ||
| 2.5 | 63 | 10 | 22 |
| 3 | 12 | ||
| 4 | 16 | ||
| 5 | 20 | ||
| 6 | 80 | 24 | 27 |
| 8 | 32 | ||
| 10 | 100 | 36 | 32 |
| 12 | 40 | ||
| 16 | 125 | 56 | |
| 20 | 60 |
Q: What are the advantages of our company?
A: Our company has professional equipment and full sets of processing solutions, we will give you the most personalized service.
Q: What is your Core Products?
A: Our Main Product is HSS & Carbide Cutting Tools.
Q: Can you supply OEM?
A: Yes, we can supply OEM and customization, but the MOQ depends on product.
Q: Do you provide samples? Is it free or extra?
A: We could offer the sample, but you need to pay the charge and the cost of freight.
Q: How long is your delivery time?
A: 5-20 days for normal order, delivery time depends on order qty. If you need to customize, the time will be calculated separately.
