Product Details:
Payment & Shipping Terms:
|
| Product Name: | Metal Working Alloy Milling Cutter | Material: | Tungsten Cobalt Alloy |
|---|---|---|---|
| Flutes:: | 2/4/6 Flute | Coating: | AlTiN, NACO BLUE, NACO BLACK, TiN Etc. |
| Application: | Carbon Steel | HRC: | 45 |
| Advantages: | High Heat Stability | Controlling Mode: | CNC Milling Machine |
| High Light: | D2 high speed steel milling cutters,6MM high speed steel milling cutters,4 flute milling cutter |
||
End Mill 4 Flute Hrc45 Coated Milling Cutters For Metal Working Tools
1.Solid carbide mill finish that is suitable for metal options like aluminum, non-ferrous, non-metallic metal
2.Precision engineered flute design that provides for superior chip removal at high feed rates
3.Allows for achieving lower cutting forces
4.Features enhanced balance and finish support
5.Helps in enhancing control as well as in bringing reduction in chatter
6.Comes with exceptional performance support
Products Features:
1. Special Cutting Edge: Special cutting edge can increase the cutting ability. The lifetime of tools and machines will be longer
2. Smooth And Wide Flute: Smooth and wide flute will remove the cuttings more easily
3. Heat-resistant Coating: With highly heat-resistant HELICA coating, can be used for high-speed processing
4. Bronze Coating: Under bronze coating, any abrasion is easy to be recognized
5. High Quality Raw Material: The raw material is used of high toughness, grain-sized carbon tungsten
6. Polished Surface Treatment: With high polished surface treatment, reduce the friction coefficient could be reduced, the lathe efficiency could be improved, more production time could be saved
Standard type
| Model No. | Flute Diameter (mm) | Flute length (mm) | Shank Diameter (mm) | Overall length (mm) |
| D1*3*D4*50 | 1 | 3 | 4 | 50 |
| D1.5*4.5*D4*50 | 1.5 | 4.5 | 4 | 50 |
| D2*6*D4*50 | 2 | 6 | 4 | 50 |
| D2.5*7*D4*50 | 2.5 | 7 | 4 | 50 |
| D3*8*D4*50 | 3 | 8 | 4 | 50 |
| D3.5*10*D4*50 | 3.5 | 10 | 4 | 50 |
| D4*10*D4*50 | 4 | 10 | 4 | 50 |
| D5*13*D6*50 | 5 | 13 | 6 | 50 |
| D6*15*D6*50 | 6 | 15 | 6 | 50 |
| D8*20*D8*60 | 8 | 20 | 8 | 60 |
| D10*25*D10*75 | 10 | 25 | 10 | 75 |
| D12*30*D12*75 | 12 | 30 | 12 | 75 |
| D14*45*D14*100 | 14 | 45 | 14 | 100 |
| D16*45*D16*100 | 16 | 45 | 16 | 100 |
| D18*45*D18*100 | 18 | 45 | 18 | 100 |
| D20*45*D20*100 | 20 | 45 | 20 | 100 |
